Vision Pro Chassis

$1,599.99

SKU VISION-600 Categories ,

We do not currently offer international shipping, follow the bottom below to find your local dealer.

When we decided we were going to start designing our new flagship chassis, we had one goal: to simply make the best, most well-thought-out, and highest-performing competition chassis that the market has ever seen.

Even though we spent countless hours designing, debating, and refinishing the smallest details, we were shocked by how well it performed when we first tested it out. But even then, we found more areas to improve to make it perform and feel even better.

The Vision Pro chassis is the result of years of feedback, testing, and dedication to give the shooting community the competition chassis they deserve. This dedication can be seen in our choice of material and in our choice of not settling for the cheapest and easiest-to-get screws that rust after one trip to the range.

ADJUST TO YOUR NEEDS

We transferred some adjustments from the Vision chassis to the Pro chassis, improved them, and added a lot of new adjustability features. The adjustable buttstock has been improved both in stiffness and feel. The forend is even longer with more M-loks and our new V-Lok attachment system, and it has the possibility to add 1 kg or 2 lbs of internal weights. And last but not least, the magazine well features height and length adjustments to get the perfect magazine fit.

ZERO VIBRATIONS

Have you ever been dry-firing and heard the vibrations in your chassis when pulling the trigger? Well, due to design and material choices, you won’t have this problem with the Vision Pro Chassis. A common fix to this issue is to add rubber parts to your chassis, but with the Vision Pro Chassis, you won’t have to even consider it.

OPTIMIZED BALANCE POINT

With the Vision PRO Chassis, we listened to feedback and moved the barricade stop as close to the magazine as we could. As a result of this and our design choices, we managed to achieve an insanely good balance point. With a full-profile 26″ barrel and zero weights, the balance point sits three inches in front of the barricade stop, which can then be moved further with the use of weights.

Superior strength

When we were deciding what material to make the Vision Pro Chassis from, we didn’t hold back, and the choice landed on 7075 aluminum. And that includes every single part, from the main body to the magazine release latch. In addition to this, walls have been made thicker, and a lot of material has been added to weak points. This has resulted in the making of the strongest and stiffest chassis on the market.

Features

Adjustable thumb rest on both sides

full length arca forend

wide & aggressive barricade stop

v-lok accessories mount

AMBIDEXTROUS & TRUE vertically ADJUSTABLE MAGAZINE LATCH

QD SLING CUPS ON FOREND AND BUTTSTOCK

DRILLED AND TAPPED HOLES FOR MOUNTING TOP COVER AND NV BRIDGE

MAGAZINE LENGTH ADJUSTMENT

RRS-LOCK INTERFACE ALONG BOTTOM SURFACE OF FOREND

AMBIDEXTROUS LH/RH ORIENTATION

Folding hinge compatible

Quick-adjust buttpad with noticable clicks

BRIDGES inside FOREND FOR superior STRENGTH

HOLE IN TRIGGER GUARD FOR EASY TRIGGER ADJUSTMENT ACCESS

ar-15 vertical grip

accessory mount

adjustable cheek rest

machined clearance in buttstock for easy barrel cleaning

Bracket rails and angles for superior stiffness and feel

11x m-loks on both sides of forend

internal and external buttstock weights compatible

Spesifications

Weight

2.52 kg / 5.55 lbs

(Base Model Remington 700 SA)

Materials

Aircraft-Grade 7075 Aluminum

finish

Elite Series Cerakote With Hard Anodized Parts.

max barrel diameter

1.350″ / 34.3mm

length

960mm / 37.8in

(Depending On Adapter Block)

forend length

480mm / 18.9in

(Depending On Model)

magazine compatibility

AICS, AW And AX Pattern Magazine Compatible.

grip compatibiliyt

Compatible With AR-15 Style Grips.

length of pull

12.25″ – 14.1″ / 311mm – 358mm (Depending On Adapter Block)

 LOP Adjustment 1LOP Adjustment 2LOP Adjustment 3
Short Adapter Block311mm / 12.24in323mm / 12.72in335mm / 13.19in
Medium Adapter block327mm / 12.87in339mm / 13.35in351mm / 13.82in
Large adapter block334mm / 13.15in346mm / 13.62in358mm / 14.09in

Specifications From Remington 700 Short Action model.

Attention to Details

Anti-vibration washers

The Vision Pro Chassis is delivered with anti-vibration washers. With these, you don’t have to worry about your action screws losing torque easily.

Black stainless steel screws

Have you ever owned a product that had rusty screws after using it once? This won’t happen with the Vision Pro Chassis due to our dedication to every little detail. In addition to this, all visible screws are black, simply because we think they look much better than shiny screws.

Compatibility

•Remington 700 SA (and clones)

More Coming soon

Contents of package

The Vision Pro chassis comes pre-built, which makes it plug-and-play for the end customer. In addition to this, all the necessary tools for installation and adjustment are included.

Here is an overview of all the included components:

Vision pro chassis base

Vision pro buttstock

vision vertical grip

adjustable thumb rest x2

Medium adapter block
